Outdoor 8MP VESTA Advanced Video Smart Dual Light Entry AI IP dome
IPC-T28-L
- Dome IP VESTA Advanced Video Smart Dual Light Entry AI for outdoor
- 8MP@20ips and H.265+
- 0.007/0.0007 lux
- Smart Dual Light with IR 30 m and white light 30 m
- Fixed lens 2.8 mm
- WDR 120 dB and digital WDR
- SMD people and vehicles
- Deterrence with white light
- Integrated microphone
- MicroSD slot up to 256GB
- IP67 protection
- 12V DC or PoE power supply
- NDAA Certification
Highlights
640 zonas
8 particiones
Vía radio SF1
Vía radio F1
Conexión IP
Conexión 2G
Conexión 4G
Z-Wave
8 MP resolution
12 V DC
Supports PoE
Night vision 20–40 m
IP67 protection rating
Digital WDR
True WDR 120 dB
H.265 video format
Supports PoE
Supports MicroSD card
P2P access
TCP/IP communication
Suitable for outdoor use
IR illumination
White light illumination
Integrated AI
NDAA compliant
Human and vehicle detection
Key features
- 1/2.8" 8-megapixel CMOS sensor
- Up to 8MP resolution
- Day/night mode
- Smart Dual Light with 1 x 30 meter IR LED and 1 x 30 meter warm-light LED
- 0.007 lux in color, 0.0007 lux in B/W and 0 lux with illumination on
- Fixed lens 2.8 mm
- 107° horizontal, 56° vertical and 127° diagonal viewing angles
- H.265+, H.264+, H.265, H.264 video formats
- Stream 1: 8MP@20 ips
- Stream 2: D1@25 fps
- Stream 3: 720P@25 ips
- BLC, HLC, 120 dB WDR, digital WDR, 3D-NR and mirror image modes
- White balance
- Automatic and manual gain control
- 4-zone video sensor
- White light deterrence
- Arming/disarming available from camera menu
- SMD intelligent motion detection for people and vehicles
- Built-in microphone
- MicroSD card slot up to 256GB (card not included)
- Reset button
- RJ45 10/100 Base-T network interface
- Network protocols TCP/IP, UDP, HTTP, IGMP, ICMP, DHCP, RTP/RTSP, DNS, DDNS, FTP, NTP, PPPOE, UPNP and SMTP
- Onvif, CGI, P2P, SDK and API support
- Compatible with IE8 and later, Chrome and Firefox browsers
- Management software
- Compatible with IOS and Android mobile devices
- 12V DC (±30%) or 802.3af PoE power supply
- Power consumption of 2.1 W in basic operation and 4.2 W max.
- Storage temperature from -40°C ~ +60°C
- Operating temperature -30°C ~ +60°C (-30°C ~ +60°C)
- Operating relative humidity less than 95%
- IP67 degree of protection
- Inner metal core and plastic housing
- Dimensions: Ø110 x 97 mm
- Net weight: 430 g
- VESTA Advanced Video Smart Dual Light Entry AI 8MP Outdoor IP Dome IPC-T28-L (IPC-T28-L)
- Equipment complies with the NDAA requirements of the National Defense Authorization Act Section 889.
Specifications
| Resolution | 8MP |
|---|---|
| Power | 12V DC, PoE |
| Audio | Microphone |
| IR Distance | 21-40m |
| Ingress protection | IP67 |
| Lens | 2.8 mm |
| Special Protection | No |
| Sensor | 1/2.8" CMOS |
| StarLight | No |
| WDR (Backlight) | D-WDR, WDR (120dB) |
| Codec | H.264, H.264+, H.265, H.265+ |
| PoE | PoE |
| SD Slot | Yes |
| Connectivity | P2P, IP, Remote P2P |
| Colour | White |
| Installation environment | Outdoor |
| Material | Plastic, Metal |
| Alarm channels | No |
| Lighting | IR, White light |
| Compatibility | Onvif |
| Series | Vesta Advanced Video |
| Onboard AI | Yes |
| Certificate | NDAA |
| Intelligent functions | SMD |
| AI Series | VESTA Entry AI |
